Minimum Opening Angle 23°
Maximum Turning Angle -45°-45°
Purified water Angle 45°-90°
Maximum Temperature 95°C
Lever Break Torque ≥12N.m
Tightening Torque 8-10N.m
Pressure VS Average Flow Rate
| P. (bar) | 0.5 | 1 | 1.5 | 2 | 2.5 | 3 | 3.5 | 4 | 4.5 | 5 |
| F. (I/min) | 6.0 | 8.4 | 10.4 | 12 | 13.4 | 14.8 | 16.2 | 17.4 | 18.6 | 19.6 |
Purified water F. (I/min) | 2.2 | 3.0 | 3.6 | 4.2 | 4.8 | 5.2 | 5.6 | 6.2 | 6.6 | 7.2 |
